| 360W-390W 166mm 60Half-Cut |
| Half-Cell High Efficiency PV Module
120 cells half cell mono solar panel
360~390W all with A Grade for on-grid & off-grid use for residential and
public rooftop & ground mounting PV Power System.
360w/360w/370w/390w |
|
120 cells 9BB half cell perc solar panel 360w/360w/370w/390w with A Grade for on-grid &off-grid&hybrid residential&industrial use for PV Power System
-
Item NO.:
SP4-60H-360-390M
-
Solar Cell :
Perc 166mm
-
Number Of Cells :
120(6*20)
-
Power Range :
360w-390w
-
Size :
1755*1038*35mm
-
Certificate :
TUV, UL, CEC, CE
-
Lead Time :
10 Days
-
Payment :
T/T, L/C, Paypal, Western Union
-
Warranty :
25 Years
Product Description
Perc Cell: The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
Electrical Characteristics
|
Module Type |
SP4-60H-360M |
SP4-60H-365M |
SP4-60H-370M |
SP4-60H-375M |
SP4-60H-380M |
SP4-60H-385M |
SP4-60H-390M |
|
Maximum Power (Pmax) |
360W |
365W |
370W |
375W |
380W |
385W |
390W |
|
Open-circuit Voltage (Voc) |
40.6V |
40.8V |
41.0V |
41.2V |
41.4V |
41.6V |
41.8V |
|
Maximum Power Voltage (Vmp) |
33.8V |
34.0V |
34.2V |
34.4V |
34.6V |
34.8V |
35.0V |
|
Short-circuit Current (Isc) |
11.24A |
11.30A |
11.36A |
11.42A |
11.48A |
11.54A |
11.60A |
|
Maximum Power Current (Imp) |
10.65A |
10.74A |
10.82A |
10.90A |
10.98A |
11.06A |
11.14A |
|
Module Efficiency(%) |
19.76% |
20.04% |
20.31% |
20.59% |
20.86% |
21.13% |
21.41% |
|
Power Tolerance |
0~+5W |
|
Temperature Coefficient of Isc |
0.05%/℃ |
|
Temperature Coefficient of Voc |
﹣0.31%/℃ |
|
Temperature Coefficient of Pmax |
﹣0.35%/℃ |
|
Standard Test Environment |
Irradiance 1000W/m², Cell Temperature 25℃，Spectrum AM 1.5 |
Packing&Delivery
31pcs/pallet, 806pcs/40HQ
|
|
|
