| 400W-415W 158.75mm 72 Half-Cut |
| Solar Panel 400-415W Mono Perc Half Cell PV Modules For Solar System |
|
144 cells 9BB half cell perc solar panel 400~415W Soliswatt Mono Half-Cut cell 158.75mm wafer with A Grade for on-grid & off-grid & hybrid residential & industrial use for PV Power System
-
Item NO.:
SP3-72H-400-415M
-
Solar Cell :
Perc 158.75mm
-
Number Of Cells :
144(6*24)
-
Power Range :
400w-415w
-
Size :
2008*1002*35mm
-
Certificate :
TUV, UL, CEC, CE
-
Lead Time :
10 Days
-
Payment :
T/T, L/C, Paypal, Western Union
-
Warranty :
25 Years
Product Description
|
Electrical Characteristics
|
Module Type
|
SP3-72H-400M
|
SP3-72H-405M
|
SP3-72H-410M
|
SP3-72H-415M
|
|
Maximum Power (Pmax)
|
400W
|
405W
|
410W
|
415W
|
|
Open-circuit Voltage (Voc)
|
49.0V
|
49.2V
|
49.4V
|
49.6V
|
|
Maximum Power Voltage (Vmp)
|
40.6V
|
40.8V
|
41.0V
|
41.2V
|
|
Short-circuit Current (Isc)
|
10.32A
|
10.35A
|
10.40A
|
10.43A
|
|
Maximum Power Current (Imp)
|
9.86A
|
9.93A
|
10.00A
|
10.08A
|
|
Module Efficiency(%)
|
19.88%
|
20.13%
|
20.38%
|
20.63%
|
|
Power Tolerance
|
0~+5W
|
|
Standard Test Environment
|
Irradiance 1000W/m2, Cell Temperature 25℃，Spectrum AM 1.5
|
Features & Benefits
First-class solar panel warranty Reliable quality
-
12-Year material & technology warranty
-
30-Year linear power output warranty
-
Soliswatt solar linear power output guarantee
-
Standard linear power output guarantee
-
Max Module Efficiency 21.4%.
Product Characteristics
-
Up to 20% generation gain from the rear-side
-
The grid line transparent back sheet increases the back reflection,and the power generation gain increases with the back light
-
More than 25% module weight lighter
-
Compared with the dual glass module, the weight is reduced by 25%,which is easy to install and save the cost of BOS
-
Low current, low hotspot and better low-irradiance performance,more stable power generation
-
Longer power output life span
-
Anti PID, low acetic acid concentration,ensure the module linear power output for 30 years
-
Strong environmental adaptability
Certified by Dust-Sand, Salt-Mist, Ammonia etc. weather resistance tests
-
Select Grade A crystalline silicon solar cells
Grade A crystalline silicon solar cells make high-power output with cost-effective
-
Packing&Delivery
31pcs/pallet, 726pcs/40HQ
|
|
|
